Nine unit substation transformers, 12.47 kV to 4.16 kV, Irving TX
Review the supplied lot information. Confirm availability and terms with your quote.
Lot details
Lot composition
Nine liquid-filled unit substation transformers in Irving, Texas, offered take-all. Price is on request. All have 12.47 kV primary and 4.16 kV secondary voltage; these are not 480 V units.
| Quantity | Rating per unit | Windings | Reported condition |
|---|---|---|---|
| 5 | 1,500 kVA | Aluminum | New 2024 Square D / Schneider Electric; never energized or commissioned, seller-reported |
| 2 | 2,000 kVA | Copper | New 2024 Square D / Schneider Electric; never energized or commissioned, seller-reported |
| 2 | 3,750 kVA | Aluminum | OEM-refurbished; set in place but never energized, seller-reported |
The 3,750 kVA units are specified at 12,470 V to 4,160Y/2,400 V. Request the manufacturer, year, serial number and refurbishment documentation for each of these two units; do not assume they share the manufacturer or year of the seven new units.
Electrical and condition review
- Match voltage, frequency, phase connection, grounding, impedance, taps, cooling ratings, BIL and terminations to the approved site design.
- Less-flammable biodegradable insulating fluid is seller-reported. Confirm the fluid product, safety data sheet, fill records and unit-specific approvals.
- Drawings, nameplates, serial lists, photos and available test records are on request for qualified buyers.
- Agree an independent inspection and acceptance-testing scope, including appropriate insulation, turns-ratio and fluid-condition checks before energization.
- Request the refurbishment scope and test records separately for the two 3,750 kVA units.
Photos and freight
The public image is an Arch Point Recovery placeholder. Reference photos are representative only; obtain current photos of the actual units before committing.
The lot is offered FOB Irving. Confirm loading responsibility, collection window and transfer of risk in the written quote. Buyer arranges suitable heavy-haul transport, permits, rigging and destination unloading. Lowboy trailers are not included. Request weights, dimensions and lifting instructions for each unit before quoting freight.
Send your project location, required voltage arrangement, intended use and buying timeline to request pricing for all nine units, inspection access and supporting records.
Specifications at a glance
| Quantity | 9 |
|---|---|
| Reported condition | Seven new 2024 units, never energized or commissioned; two OEM-refurbished units set in place but never energized, seller-reported |
| Location | Irving, Texas, USA |
| Manufacturer | Square D / Schneider Electric for the seven new units; manufacturer of the two refurbished units to be confirmed from nameplates |
| Model | Liquid-filled unit substation transformers; serial-specific model numbers on request |
| Supplied specifications | 12.47 kV primary to 4.16 kV secondary, not 480 V. Five x 1,500 kVA, aluminum windings; two x 2,000 kVA, copper windings; two x 3,750 kVA, aluminum windings, 12,470 to 4,160Y/2,400 V. Less-flammable biodegradable fluid, seller-reported; exact fluid and nameplate configuration on request. |
| Testing / data handling | Drawings, nameplates, serial numbers, photos and available test records on request for qualified buyers. Agree independent acceptance testing before energization. |
| Pickup / shipping | Take-all, FOB Irving as offered; confirm loading and transfer-of-risk terms in the written quote. Buyer-arranged heavy haul. Lowboy trailers are not included. |
| Asking price | On request |
Reference: lot-3b5bf1ac5741 · Listed 2026-10-01 · Updated 2026-10-01. Details above are supplied lot information; request supporting records for your purchase.
Before purchase
Confirm the exact configuration, included accessories, available quantity, test results, data-sanitization status where applicable, and freight arrangements. Photos alone do not establish testing, warranty coverage or fitness for your application.
